Safe and reliable electrical components for your True OEM cooler.
START COMPNT KIT POWER PAC W/OVERLOAD 954415/985077 INCLUDES; 954415 OVERLOAD AND 985077 POWERPAC THAT INCLUDES 949687 RELAY, 949686 START CAP, 968402 RUN CAP, 985089 WIRE HARNESS FOR USE WITH COMPRESSOR NT2160UV 842GG02D7BZ (985074)..
START COMPNT KIT DLE4.0CN INCLUDES, 997806 RELAY, 997808 RUN CAP. FOR USE USE WITH 997810 DLE4.0CN AND 206938 DLE4.8CN
START COMPNT KIT AJ532AT-430- B4 AJA2425ZXA INCLUDES; 802234 RELAY, 802233 OVERLOAD, 802238 START CAP, 931286 RUN CAP FOR USE WITH 842092 (AJ532AT) AJA2425ZXA..6/2017 LG...
RELAY KIT, G7L-2A-TUB-CB-AC200 /240 INCLUDES: 842623 RELAY, 2) 802179 TERMINAL, AND 839670 PRODUCT ADVISEMENT RELAY CONTROLS TEMPERATURE CONTROL, TIMER FOR BOTH DEFROST AND REVERSE FAN MOTOR, DEFROST TERMINATION SWITCH AND FAN DELAY SWITCH.
MOTOR, PSC4BG14M1 115V 60HZ 14 WATT, PSC USE TILL DEPLETED. REPLACE WITH 830037 KIT, PCN-12106. USE TILL DEPLETED. ONCE DEPLETED CONTACT PARTS DATA MANAGEMENT E-MAIL GROUP FOR REPLACEMENT OPTIONS 14 WATT
EVAP FAN RETROFIT KIT INCLUDES: 1) 225824 WELLINGTON MOTOR, 1) 863476 MOTOR BASE, 2) 214606 CONNECTORS, 1) 820016 NUT, 3) 210680 SCREWS, 1) 205723 INSTRUCTIONS. (THE 993202 WELLINGTON MOTOR WAS USED 1/18/17 TILL 10/17/17 PER PCN 9636) THIS KIT WILL REPLACE THE FOLLOWING EBM MOTORS: 993949 / 206504 RETROFIT KITS (948823 MOTORS) AND 912108 / 973080 MOTORS AND IS ONLY USED WHEN REPLACING THESE MOTORS IN THE FIELD.
WIRE HARNESS, MALE 8017, 33" MALE PLUG EMF P-7-1 PVC WHT HAS WHIE MALE PLUG EMF P-71 WITH 7 PINS WITH 7 33" LEADS. RED LEAD HAS STEPDOWN INSULATED BUTT SPLICE, BLACK WIRE HAS #10 RING TERMINAL, GREEN WIRE HAS #10 LOCKING FORK TERMINAL, WHITE WIRE HAS #10 RING, YELLOW WIRE HAS STEPDOWN INSULATED BUTT SPLICE, 2 BLUE WIRES HAVE NO TERMINALS.
POWER CORD, DOOR 27" Y SPLIT 2/3 DOOR MOLEX CONNECTORS ALL VOLTAGE. GOES FROM BALLAST BOX TO 20" DOOR POWER CORD.
WIRE HARNESS, TUC, TWT WITH NEMA 5-15P PLUG CORD TO WALL OUTLET. HAS OUTLET FOR COMPRESSOR POWER CORD AND 4 LEADS FOR THE TEMP CONTROL, FAN, EVAP MOTOR.
TEMP CONTROL, ETC1H REF 230V THIS IS THE UNPROGRAMMED CONTROL. NEED MODEL AND SERIAL NUMBER TO PROGRAM
PROBE, THERMISTOR 4M, NTC EPC #B57025M2502A7 SECONDARY DEFROST PROBE / SINGLE BLUE STRIPE
CAP, INSULATED E27/E26 WHITE SNAP IN FOOT #22.945-301.50 USE WITH 960641
C_KIT, CONTROL RELAY INCLUDES: 841889 RELAY, 901878 WIRE ASM BLK/BLUSTR 16G 18", WIRE 16G/BLUSTR BNRD18", WIRE 14G WHBU 4", WIRE 18G WHT/BLUSTR 24", WIRE 18G BN/PNST18" 2) 830592 SCREW, 2) 202747 CONNECTOR 5 WAY, 2) CONNECTOR 2 WAY, CONNECTOR 3 WAY, 902770 INSTRUCTION,
TIMER, DEFROST XC2001-21 8HR/20 MIN 220V 50 HZ 8HR/20 MIN 220V 50 HZ.. REPLACES THE 831921 M-178-1 230V 50/60 HZ 6HR/20 MIN
SWITCH, TOGGLE, 2GK721-D-4B-B ON/OFF POWER SWITCH LOCATED IN TIME CLOCK BOX
RELAY, RP6708-ZR COMPELA 820-10031 THIS CAN BE PURCHASED INDIVIDUALLY OR AS A KIT. REPLACE W/ START COMPNT KIT 205042 TO USE W/COMPRESSOR 984085 AE4440Y-AA1A AE-1383-E....LG 6/2017
CAPACITOR, START 2252291 64-77uF, 330V THIS CAN BE PURCHASED INDIVIDUALLY OR AS A KIT. USE PWR PAC 969637 FOR USE WITH (979678) NT2180U- COMPRESSOR
OVERLOAD, 8300MRAR16 MRA5775-34 THIS CAN BE PURCHASED INDIVIDUALLY OR AS A KIT. USE START KIT (213126) FOR COMPRESSOR (963040) TPA9421YXA TP119AR-021-E4KX. REPLACES THE 802289 OVERLOAD PREVIOUSLY USED.
START COMPNT KIT NEK2125GK 957EG71D6AQ FOR COMPRESSOR 842514 NEK2125GK (957EG71D6AQ) INCLUDES 915448 RELAY 915449 OVERLOAD 915450 START CAPACITOR
RELAY, 213515003 3,75A 115V THIS CAN BE PURCHASED INDIVIDUALLY OR AS A KIT. START COMPNT KIT (971627) FOR USE W/ COMPRESSOR (952421) 513307345991.E EMI50UER 115V/60HZ R290..LG 6-2017..... REPLACE W/START COMPNT KIT (950667) FOR USE W/COMPRESSOR (945032) EMIS30HHR..LG 6/2017...
START COMPNT KIT NT6215Z CSR 115V INCLUDES: 915103 OVERLOAD, 842463 RELAY, 915104 START CAPACITOR, 955151 RUN CAPACITOR
