True Parts OEM - GDM-41SL-54-HC: Find authentic replacement parts and accessories for your True OEM cooler, designed to ensure optimal performance, durability, and reliability.
UNIT GDM-33CPT/41CPT-HC INCLUDES 213142 COMPRESSOR WITH START COMPONENTS, 803117 BRACKET, 854926 MOTOR, 963186 BLADE, 803118 COIL, 803119 SHROUD, 997816 LOOP, 925928 DRIER, 922097 DRAIN PAN, WICK ASSEMBLY, 205980 WIRE HARNESS ALL MOUNTED TO A BASE.
LEVER CONNECTOR KIT INCLUDES: 3) 995655 3-WAY LEVER CONNECTORS, 3) 202747 5-WAY LEVER CONNECTORS
PROBE, THERMISTOR 1M EPC B57025M2103A018 USED TO REPLACE PROBES FROM KIT 844950
CONTROL KIT, TEC22 CONTAINS: 1) 834327 CONTROL ASSEMBLY, 1) 834326 KNOB, 2) 210680 SCREW, 1) 808218 PROBE, 1) 808219 PROBE, AND 1) 844949 INSTRUCTIONS, 1) 998598 WIRE WHBU, 1) 919558 WIRE BLK, 3) 802179 BLST, 2) 2WAY LEVER CONNECTOR, 1) 3WAY LEVER CONNECTOR, 1) 5 WAY CONNECTOR, 6) 802149 CABLE TIE, 2) 802207 1/4 CLAMP, 4) 3/16 CLAMP. 6) 830592 SCREW, 2) 990592 SCREW,
UNIVERSAL CONTROL KIT, TEMP FCA23 UPS OLD#S ARE UTD REPLACES 985434, 991224, 845563, 847649. 846763,952478 INCLUDES: 837360 TEMP CONTROL, 837358 KNOB, 2) 210680 SCREW, 995941 PROBE, 995942 PROBE, 841889 RELAY,2) 901878 WIRE ASM, 901879 WIRE ASM, 919558 WIRE ASM, 913157 WIRE ASM,842199 TERMINAL, 802179 TERMINAL, 802128 TERMINAL, 200962 CONNECTOR,6) 995655 ONECTOR, 202747 CONNRCTOR,6) 802149 CABLE TIE, 2) 802207 CLAMP, 4) 802259 CLAMP, 2) 990592 SCREW, 845565 INSTRUCTIONS.
CONTROL, ERC112D TRUE *SERIAL NUMBER NEEDED TO PROGRAM *REPLACES 835415.OR USE UNIVERSAL KIT 848288
PROBE, THERMISTOR 4M W/STRIPES B57025M2103A57 BLUE STRIPE
PROBE, THERMISTOR 4M B57025M2103A58 THERMOSTAT SENSOR / NO STRIPE
TEMP CONTROL, PQ 115V PROGRAMABLE NEED SERIAL NUMBER TO BE PROGRAMMED TO COOLER / FREEZER
PROBE, 6mm BLACK 1.5M 24AWG 6MM BLACK 1.5MUSED WITH SOLLATEK CONTROL. SENSING AIR SUPPLY.FAILED PARTS TO BE RETURNED VIA CALL TAG
PROBE, 6mm WHITE 1.5M 24AWG REPLACED THE 9685376MM WHITE 1.5MUSED WITH SOLLATEK CONTROL READ COIL TEMP.FAILED PARTS TO BE RETURNED VIA CALL TAG
POWER CORD, 160" NEMA 5-15P 14/3 SJT 15 AMP, 125V (ONLY USED IN SPECIAL APPLICATIONS)
POWER CORD, 108" NEMA 5-15P 14/3 SJT POWER CORD TO WALL OUTLET, 15 AMP HAS THREE PRONG PLUG
POWER CORD, 132" NEMA 5-15P 14/3 SJTOW POWER CORD TO WALL OUTLET, 15 AMP HAS THREE PRONG PLUG. REPLACES THE 801701 WHEN LONGER CORD IS REQUIRED.
EVAP COVER ASM GDM-41SL-60 INCLUDES 992540 COVER, 8101203 GROMMET, DRAIN ELBOW, 992539 DRAIN PAN AND FAN GUARD.
COVER KIT LINE SET GDM/T BLK INCLUDES 207846, 207849 COVERS, 6)830592 SCREWS, 2)811212 BUSHING AND 209719 INSTRUCTION
EVAP COVER ASM GDM-41SL BLK INCLUDES: 992541 COVER, 810203 GROMMET, 992539 DRAIN PAN, 968054 NOZZLE, 811514 SCREW, 860198 TEMP CONTROL COVER, 919512 FAN COVER
WIREWAY COVER KIT INCLUDES: 1) 967148 COVER, 4) 830592 SCREWSCOVERS WIRES THAT ARE LOCATED IN COMPRESSOR AREA AND ATTACHES TO BOTTOM OF TANK BOTTOM. HAS A U SHAPED CHANNEL.
CROSSRAIL COVER BTM, GDM-41/SL BLK LOCATED ON CABINET DIRECTLY BELOW DOORS.
