True Parts OEM - TBB-24-72FR-S: Find authentic replacement parts and accessories for your True OEM cooler, designed to ensure optimal performance, durability, and reliability.
UNIT 1/5 134 TPA0413YXA TBB-24-72FR INCLUDES: COMPRESSOR WITH RUBBER MOUNTING BLOCKS, RELAY, OVERLOAD, START CAPACITOR, FAN MOTOR, FAN BLADE, DRIER, CONDENSING COIL, SHROUD, DRIER, POWER CORD ALL MOUNTED TO BASE.
FITTING, 1/2" X 1/2" STRAIGHT BARB HIGH DENSITY POLYETHYLENE USED TO CONNECT TWO DRAIN HOSE.
WHT 1/2" X 1/2" STRAIGHT BARBED FITTING USED TO CONNECT TWO DRAIN HOSE.
TEMP CONTROL, 077B6806 KIT #077B7172 . REPLACE WITH REFROFIT KIT 882636 IF UNIT WAS BUILT W/RELAY.INCLUDES: KNOB AND SCREWS. WILL REPLACE THE 963056 CONTROL PER PCN 7784
POWER CORD, 92", 5-15P, 115V 16-3 SJTWA #3 WIRE HARNESS CORD TO WALL OUTLET. HAS OUTLET FOR COMPRESSOR POWER CORD AND 4 LEADS FOR THE TEMP CONTROL, FAN, EVAP MOTOR. 15 AMP
POWER CORD, COMP C1147 W/AMP 40589 #10 RING 2 RINGS AND ONE HORSESHOE CONNECTORS
ADAPTOR, DRAIN PAN FOR ONE PC PAN HEATER CORD USED W/ 801814/801879 HEATED DRAIN PANS.
POWER CORD, 14/3 SJTOW WITHOUT PLUG 300 VOLT, NO PLUG ON CORD
CORD KIT, COMP 8 PIN W/FLANGE TERMINAL 115V INCLUDES:1) 915105 8 PIN CORD FROM COMPRESSOR POWER CORD TO COMPRESSOR START COMPONENTS, 1) 951657 16G GREEN/YELLOW WIRE ASM, 1) 943326 16 G WHITE 12 MALE AMP WIRE ASM, 1) 943325 16G BLACK 12 MALE AMP WIRE ASSMREPLACES 965713, 937374 AND 917607, 925765, 931551 AND 925766, 937374
COUNTERTOP SILICONE KIT TD/GC/TBB/TBR/TDR CONTAINS: 1) 820560 SEALANT, NEW ADVISEMENT
EVAP COVER ASM TBB-2/3/4 '00 DESIGN FOR ROCKER SWITCH CUT OUT AT BOTTOM OF LEFT CORNER & ROCKER SWITCH W/ ONE FAN OPENINGINCLUDES: 994303 EVAP FAN BLADE COVER, 995682 EVAP FRONT COVER, 995806 DRIP PAN, 938024/832271 NOZZLE/SCREW, 842250 ROCKER SWITCH, TAPE AND SCREWS
EVAP COVER TOP, TBB-24-48/60 ALL, TPDB-48-24 CLEAR (WHT REV ATTACHES TO THE FRONT EVAPORATOR SCREEN. WITH 9)830592 8-18 X 1/2" HEX WA HD SCREWS
SKID KIT, TBB-24-72 INCLUDES: 2) SKID MTG. BRACKETS 860917, 2)963681 SKID MOUNT BRACKET 4) SCREWS 830535, 4)830520 SCREWS 1) 206324 SKID ASSEMBLY
DRIER, 1/4 & 3/8 INLET; 3/16 OUTLET #CUD100601-TRU DRIER 5/16" & 3/8" INLET; 3/16 OUTLET
NOZZLE & SCREW SET, STRAIGHT H.I.P.S WHT INCLUDES 938116 WHITE STRAIGHT NOZZLE & 832271 SCREW. USED ON CABINETS WITH WHITE INTERIORS
GRILL ASM TBB-24-48/60 BLK INCLUDES 1)997024-027 GRILL, 1)200931 NAMEPLATE
GRILL KIT TBB-24-48/60/72 SS INCLUDES 915573 GRILL, 2)830596 SCREWS AND 1)820343 NAMEPLATE
HANDLE KIT RECESSED HANDLE FIELD RETROFIT INCLUDES: 1)954427 HANDLE, 6)954428 CLIPS, 1)811311 DRILL BIT, 1 TUBE 992535) BLACK SEALANT, 954429 INSTALLATION INSTRUCTIONS.
HANDLE KIT RECESSED HANDLE FIELD RETROFIT 3 DOOR INCLUDES: 3)954427 HANDLE, 18)954428 CLIPS, 1)811311 DRILL BIT, 1 TUBE 992535) BLACK SEALANT, 954429 INSTALLATION INSTRUCTIONS.
DRAIN PAN, HEATED 115V 2799-1262-2000 ONE PIECE HEATER AND PAN WITH CIRCUIT BREAKER IN POWER CORD. 160 WATT. REQUIRES AN 801740 POWER CORD ADAPTOR AND A METAL DRAIN PAN WITH HOLE FOR HEATER TO SET IN.
