True Parts OEM - TG2F-2S STARBUCKS: Find authentic replacement parts and accessories for your True OEM cooler, designed to ensure optimal performance, durability, and reliability.
HINGE KIT DOOR BTM LH TM-GLASS TA/TG/TR-1/2/3 F/R/PT INCLUDES: 1) 931094 HINGE BRACKET ASSY (893850), 1) 832103 STOP PIN, 3) 830906 WASHERS, 3) 860613 WASHERS, 3) 830537 SCREWS, 1) 832108 SHAFT, 1) 914556 SHIM, 2) 923096 SHIM, 204380 LOCTITE, 1) 844402 FLANGE BEARING, AND INSTRUCTIONS
HINGE KIT DOOR BTM RH T/S TM-GLASS TA/TG/TR-1/2/3 F/R/PT INCLUDES: 1) 931095 HINGE BRACKET ASSY (893849), 1) 832103 STOP PIN, 3) 830906 WASHERS, 3) 830613 WASHERS, 3) 830537 SCREWS, 1) 832108 SHAFT, 204380 LOCTITE, 1) 844402 FLANGE BEARING, AND INSTRUCTIONS
SPRING KIT, DOOR TM24/52/74/ TR 1/2/3 INCLUDES: 1)931577 TORSION SPRING W/ 1)832110 BRASS BUSHINGS, 1 832182 BUSHING
HINGE KIT DOOR TOP LH TR DOES NOT HAVE SHAFT/STOP PIN INCLUDES: 1)936639 HINGE BRACKET ASSEMBLY, 1)830633 WASHER, 2)830906 WASHERS, & 2)830537 SCREWS.
HINGE KIT DOOR TOP RH TR INCLUDES: 1)908400 HINGE BRACKET ASSY, 1)830633 WASHER, 2)830906 WASHERS, & 2)830537 SCREWS.
FOAM, 1# WHT EPS 1/2 X 3/4 TAPERED 11 1/2 X 42 CUT STYROFOAM TO FIT ACCORDING TO APPLICATION
KEY, K54G 2K STP CD,BIT & RING M5300021120001J INCLUDES 2 KEYS. REPLACES 831306
HOT KEY DIXELL DK00000100 PROGRAMMING KEY ONLY USED ON UNITS BUILT WITH DIXELL ELECTRONIC CONTROLS
WICK KIT 1)963070 6)83192O TA/TG/TR1 INCLUDES: 963070 WICK BAR, 6)831920 PADS, 2)830592 SCREWS
LIGHT COVER, TR1F/2F/3F 14 3/16" INCLUDES 810359 CUT DOWN FROM 21" TO 13 13/16"
EVAP LID ASM TA/TG TR2F INCLUDES : 2)890192 EVAP LID TOP/BTM, 2)938326 PLASTIC, 2977717 PLASTIC , 4)860931 PLATES, 4)863624 BRACKET AND 4) 830805 POP RIVET.
LINE SET, TR2F-2S R404A 7' X .064"ID INCLUDES: 870010 ACCUMULATOR, 867432 COPPER STRAIGHT TUBE, 915404 SUCTION LINE, 820223 TAPE, AND 851147 CAP TUBE
COPPER REDUCER 1/2 X 3/8" USED TO CONNECT THE SUCTION LINE TO THE PULLOUT TO REDUCE REFRIGERATION LEAKS
LINE SET, TR2F-2S R404A 12' X .064 ID INCLUDES 870010 ACCUMULATIOR, 867432 COPPER TUBE STRAITGHT, 915404 1/2" SUCTION LINE, 851134 .064 X 12' CAPILLARY TUBE
MOTOR, ESP-L35EM1 115V 60HZ 35 WATT USE TILL DEPLETED. ONCE DEPLETED CONTACT PARTS DATA MANAGEMENT E-MAIL GROUP FOR REPLACEMENT OPTIONS35 WATT. SELF CONTAINED MOTOR AND BLADE WITH POWER CORD
FAN MOTOR RETROFIT KIT INCLUDES: 817939 MOTOR, 3) 202747 CONNECTORS, AND 817938 INSTRUCTIONS. WARRANTY MUST ISSUE A CALL TAG – SEE CALL TAG LIST
FAN MOTOR KIT 115V NO BLADE USE TILL DEPLETED. REPLACE WITH 243072 PCN-15300INCLUDES: 837869 16W FAN MOTOR, 3) 202747 CONNECTORS, 2) 826842 T-BOLTS, 3) 824083 SCREWS, 3) 818619 SCREWS, 4) 824082 FLANGED NUTS, 824085 SLOTTED WASHER, 826849 DRIVE PLATE, 956425 BRACKET, 949491 BRACKET, AND 830033 INSTRUCTIONS. DOES NOT INCLUDE BLADESPEED 1 IN CLOCKWISE FROM THE REAR. SPEED 2 IS COUNTERCLOCKWISE FOR 30 SECONDS, THEN COUNTERCLOCKWISE FROM THE REAR. 1550 RPM
MULLION ASM TR-2/3 F/R INCLUDES: POST, COVER AND HEATER WIRE
NAMEPLATE, TRUE FREEZER 51171-P HAS TWO WAY TAPE ON BACK OF NAMEPLATE. REPLACES THE 820345 WHEN STOCK IS DEPLETED.
NAMEPLATE, TRUE TR FREEZER DRAWING C989 GOES BEHIND EXTERIOR THERMOMETER. FOR 831925/831958 THERMOMETER. HAS TRUE FREEZER ON PLATE.
