True Parts OEM - TGU-2: Find authentic replacement parts and accessories for your True OEM cooler, designed to ensure optimal performance, durability, and reliability.
WIRE HARNESS, MALE 8017, 33" MALE PLUG EMF P-7-1 PVC WHT HAS WHIE MALE PLUG EMF P-71 WITH 7 PINS WITH 7 33" LEADS. RED LEAD HAS STEPDOWN INSULATED BUTT SPLICE, BLACK WIRE HAS #10 RING TERMINAL, GREEN WIRE HAS #10 LOCKING FORK TERMINAL, WHITE WIRE HAS #10 RING, YELLOW WIRE HAS STEPDOWN INSULATED BUTT SPLICE, 2 BLUE WIRES HAVE NO TERMINALS.
POWER CORD, #3 FOR VDE/CE WITH OVER-TINNED ENDS HARNESS THIS #3 WIRE HARNESS HAS A CENTER BLOCK WITH ONE LEAD OFF IT TO CONNECT TO MAIN POWER CORD; ONE LEAD WITH RECEPTACLE TO PLUG COMPRESSOR POWER CORD INTO IT AND 4 LEADS FOR TEMP CONTROL/FANS
POWER CORD, COMP 787MM+10mm, C-14R PLUG, 32/0.20mm WITH HEAT SHRINK TUBING AND SPRING SPADE TERMINALS OVER WIRE CRIMPS.
POWER CORD, COMP 30 3/4" IEC- 320-2,W/1-480764-0 AMP CONNECT W/1-480764-0 AMP CONNECTOR
POWER CORD, MOTOR 23.6" EBM W/FERRULES, 10330-4-1040 USED WITH 943820 MOTOR & 952207 MOTORUSE WITH 9438358 MOTOR M1G055-BD91-15.WILL REPLACE 943695 CORD WHEN DEPLEATED
TEMP CONTROL PLATE, ALUM HAS V SHAPED NOTCH CUT OUT. USED TO SET TEMPERATURE DIAL.
PAPER TUBE, TSSU (ALL) 2 1/2OD X 2 1/2L X 1/4 SAW CUT REQUIRES 4 PER CABINET. LOCATED BETWEEN SKID AND FRAME OF CABINET FOR SHIPPING.
SKID ASM TGU-2/2F INCLUDES: 2)919228 WOOD, 3)820414 WOOD, 42)980630 NAIL
DOOR ASM TGU-2/3/F LH REC 17 5/16"W X 26 3/16"H INCLUDES: GASKETCONFIRM LOCK LOCATION BEFORE ORDERS ARE PLACED.
DOOR ASM TGU-2/3/F RH REC 17 5/16"W X 26 3/16"H INCLUDES: GASKET 811422CONFIRM LOCK LOCATION BEFORE ORDERS ARE PLACED.
COPPER U-BEND EPC #27523 LOCATED IN BOTTOM CONDENSATE PAN. ATTACHES TO DRAIN HOSE W/ 830305 TIE WRAP INCLUDED
DRIER, 1/4 & 3/8 INLET; 3/16 OUTLET #CUD100601-TRU DRIER 5/16" & 3/8" INLET; 3/16 OUTLET
DRIER, 4.5"L SPUN COPPER DRIER W/ 2) 1/4" INLETS AND 1) 3/16" OUTLET
ELBOW, DRAIN SWIVEL GRAY 1/2"NOM.COMB.INSERT X FPT GREY SWIVEL ELBOW
NOZZLE & SCREW KIT 980760/8115 08 INCLUDES: 1)980760 NOZZLE WHITE 90 DEGREE, 1)811508 SCREW
GASKET BASE KIT TGU/TGW-2F LOCATED ON CABINET "NOT ON DOOR". SURROUNDS DOOR OPENING. INSERTS INTO PERIMETER PLASTIC. 4 PIECE ASSEMBLY.
GASKET BASE SS VERT CENTER TGU-2/3 LOCATED ON CABINET'S CENTER MULLION BETWEEN DOORS.
GRILL KIT, TGU/TGW SS FOR/MECH CONTROL INCLUDES: 893095 GRILL, 1)917991 AND 917992 GRILL SUPPORT, 8) 830592 SCREWS
GROMMET, 2 1/8"ID FOR 2 1/2" OPENING MFG PART NO. INSERTED INTO GRILL TO PROTECT CORD.
