True Parts OEM - TM-52G: Find authentic replacement parts and accessories for your True OEM cooler, designed to ensure optimal performance, durability, and reliability.
HINGE KIT DOOR BTM RH T/S TM-GLASS TA/TG/TR-1/2/3 F/R/PT INCLUDES: 1) 931095 HINGE BRACKET ASSY (893849), 1) 832103 STOP PIN, 3) 830906 WASHERS, 3) 830613 WASHERS, 3) 830537 SCREWS, 1) 832108 SHAFT, 204380 LOCTITE, 1) 844402 FLANGE BEARING, AND INSTRUCTIONS
SPRING KIT, DOOR TM24/52/74/ TR 1/2/3 INCLUDES: 1)931577 TORSION SPRING W/ 1)832110 BRASS BUSHINGS, 1 832182 BUSHING
FOAM, 1# WHT EPS 1/2 X 3/4 TAPERED 11 1/2 X 42 CUT STYROFOAM TO FIT ACCORDING TO APPLICATION
KEY, K54G 2K STP CD,BIT & RING M5300021120001J INCLUDES 2 KEYS. REPLACES 831306
KEY, # A-001 FOR LOCK 831373 & 917625 INCLUDES 2 KEYS. FOR 831373, 924896, AND 917625 LOCKS, 93564, 206239 LOCK
LAMP, F032/865/XP/ECO 48" THIS LAMP WILL RETROFIT T-8 801125 LAMP. IT DOES NOT RETROFIT THE 801132 LAMPS.BLUISH WHITE
LAMPHOLDER, 13570 SPRINGLOADED TELESCOPING SPRINGLOADED (ONE) NOTE DESIGN CHANGE BY MANUFACTURER CHANGED SHAPE OF SOCKET AREA FROM ROUND TO OVAL...WILL RETROFIT.
LAMPHOLDER, 13571 STATIONARY STATIONARY (ONE) NOTE DESIGN CHANGE BY MANUFACTURER CHANGED SHAPE OF SOCKET AREA FROM ROUND TO OVAL...WILL RETROFIT.
LAMPHOLDER KIT, 542 KULKA W/52" LEADS NO REPLACEMENT. ONLY OPTION IS TO UPDATE TO LED LIGHTING.INCLUDES: 842111 LAMPHOLDER WITH 916327 LEADS IF REPLACING 801230 IT IS RECOMMENDED TO REPLACE THE OPPOSITE LAMPHOLDER WITH 839627. PER TDN-0607
LAMPSHIELD, 46 1/4" X 1-5/8"OD T-12 WITH END CAPS INCLUDES: LAMPSHIELD AND TWO END CAPS
LEG, 6" 1/2-13 X 1" EQUIPMENT AE61-4002-CAF NICKEL FINISH EXPOSED STEM. ADJUSTS FROM 6" TO 7-1/2". ZINC DIE CAST, TOP DIAMENTER OF LEG IS 2 1/4"
LEG, 6" ADJUSTABLE FLUSH STUD 6165800BN5F4 FOR FRAMED STYLE LEG ASSEMBLY. ADJUSTS FROM 6" TO 7-1/2". MADE OF ZINC DIE CAST.
LEG, 6" 1/2-13 x 1" SEISMIC STEM ADJUSTABLE STAINLESS BOTH TOP AND BOTTOM PIECE. EXPOSED STEM. USED TO BOLT COOLER TO FLOOR. ADJUST 6" TO 8". 3-1/2" DIAMETER BASE PLATE WITH 2) 7/16"HOLES FOR BOLTS PLACED 2-1/2" CENTER TO CENTER. TOP DIAMENTER OF LEG IS 2 1/4"
LEG KIT 6" 4)830409 1/2" STEM GDM/T/TM/TR/TSSU/TPP ADJUSTS FROM 6" TO 7-1/2". MADE OF ZINC DIE CAST. 4)830409 LEGS & SCREWS. TOP DIAMETER IS 2 1/4"
LEG KIT 6" 4)830437 SEISMIC 1/2" STEM INCLUDES: 4)830437 LEGS. LEG HAS TWO HOLES IN FOOT TO USE SCREWS TO SECURE TO FLOOR. LEGS ADJUST FROM 6" TO 8". STAINLESS STEEL. 3-1/2" DIAMETER BASE PLATE WITH 2) 7/16"HOLES FOR BOLTS PLACED 2-1/2" CENTER TO CENTER.
LINE SET, TM-52 R134A 12' x .064" ID 851134 CAP TUBE, 866743 ACCUMULATOR, 932008 COPPER ELBOW, 953789 ACCUMULATOR, 932006 COPPER ELBOW, 820223 TAPE
COPPER REDUCER 1/2 X 3/8" USED TO CONNECT THE SUCTION LINE TO THE PULLOUT TO REDUCE REFRIGERATION LEAKS
LOCK KIT T SERIES SOLID/GDM INCLUDES FROM MANUFACTURER: 831373 LOCK, 927444 CAM, LOCK NUT, WASHER, SCREW, & 2 (932992) KEYS.
NAMEPLATE, TRUE REFRIGERATOR T COOLER & TSSU'S LOCATED ON THE GRILL OR DOOR.
NUT, 8-32 HEX NUT, 18-8 STAINLESS FOR SCREW ON CENTER STANDARD
RECEPTACLE, 3 WAY BLK #413-01374-001 15 AMP LOCATED NEXT TO THE BALLAST BOX FOR COMPRESSOR. LOCATED ON BACK OF CABINET AS CONVENIENCE OUTLET ON SOME MODELS. FOR 3 PIN PLUG
EVAP DRAIN PAN ASM TM-52 NEW DRAIN HOLE 5-1/2" FROM EDGE. INCLUDES 1)862253 PAN W/ 1/2" COPPER DRAIN TUBE.
