True Parts OEM - TS-49G: Find authentic replacement parts and accessories for your True OEM cooler, designed to ensure optimal performance, durability, and reliability.
DOOR ASM T-49G-LD LH, 24V IDL RETROFIT INCLUDES: 848364 DOOR ASM, 2) 832292 SCREWS,968011 HANDLE, 2) 908621 SPCERS, 4) 919286, 216945 POWER SUPPLY, 6) 5WAY CONNECTORS, 2) 830592 SCREWS, 810719 GASKET, 215777 TENSION SCREW.
RETAINER KIT DOOR GASKET GDM-19,23,49 2)54-1/4 2)26-5/8 4 PIECES, ON DOOR HOLDS GASKET. INCLUDES: 2)867690 TOP/BOTTOM BACKPLATE, 2)867699 SIDE BACKPLATES 16)830569 SCREWS
SPRING KIT, DOOR GDM/T-SERIES 52 3/8" W/2)832110 BRASS BUSH TORSION STYLE, INCLUDES: 1)925005 SPRING ASSY(SPRING WITH PLASTIC TUBE, 2)832110 BRASS BUSHINGS
GASKET RETAINER KIT GDM-19/23 49/F/PT/RL, NWDG INCLUDES: 2)928839 PCS OF BLACK PLASTIC, 2)928840 PCS OF BLACK PLASTIC, & 16)830569 SCREWS.
GASKET RETAINER KIT GDM-23 LD T-23 LD 4 PIECES ON DOOR TO HOLD GASKET. INCLUDES: 2) 942244 , 2) 943541, & SCREWS
DOOR ASM T-49G-LD RH INCLUDES DOOR ASSEMBLY W/ CARTRIDGE SPRING, WIDE DOOR GASKET, & HANDLE(TO RETROFIT USE 929905 TOP HINGE SHAFT AND 2)905244 DOOR HINGE SHIMS WHICH COME WITH DOOR) INCLUDES 8)938357 LED LIGHT MODULES
DOOR ASM T-49G-LD LH INCLUDES LEFT DOOR ASSEMBLY W/ CARTRIDGE SPRING, WIDE DOOR GASKET, & HANDLE(TO RETROFIT USE 929905 TOP HINGE SHAFT AND 2)905244 DOOR HINGE SHIMS WHICH COME WITH DOOR) INCLUDES 8)938357 LED LIGHT MODULES
DOOR ASM T-49G-LD RH WIRE HIDE INCLUDES RIGHT DOOR ASSEMBLY WITH CARTRIDGE SPRING, WIDE DOOR GASKET, HANDLE AND 2)962758 LED LIGHT MODULES
DOOR ASM T-49G-LD LH WIRE HIDE INCLUDES LEFT DOOR ASSEMBLY WITH CARTRIDGE SPRING, WIDE DOOR GASKET, HANDLE AND 2)962758 LED LIGHT MODULES
DRIER, 1/4 & 3/8 INLET; 3/16 OUTLET #CUD100601-TRU DRIER 5/16" & 3/8" INLET; 3/16 OUTLET
DRIER, 4.5"L SPUN COPPER DRIER W/ 2) 1/4" INLETS AND 1) 3/16" OUTLET
NOZZLE & SCREW, BLK FC FREEZER INCLUDES 938020 BLACK ANGLED NOZZLE & 811514 SCREW. USED ALSO ON CABINETS WITH BLACK OR STAINLESS INTERIORS PER PCN 7844
NOZZLE & SCREW SET H.I.P.S. NAT. ANGLED INCLUDES 938024 WHITE ANGLED NOZZLE & 811508 SCREW
GASKET BASE SS VERT CENTER GDM/T 2 13/16 X 52 5/8 LOCATED ON CABINET BETWEEN THE DOORS.
GASKET BASE SS ASM GDM-F/T-49 F LOCATED ON CABINET "NOT ON DOOR". SURROUNDS DOOR OPENING. INSERTS INTO PERIMETER PLASTIC. 4 PIECE ASSEMBLY. INCLUDES: 2)992590 VERTICAL GASKET BASES & 2)992581 HORIZONTAL GASKET BASES.
GRILL ASM T-49/F/G RH MAGNET 54"W X 11 3/4"H X 2 3/4" INCLUDES: 5) ROUNDED LOUVERS 893742, 1) LEFT ROUNDED LOUVER END 906014, 1) RIGHT ROUNDED LOUVER END 893751, 12) SCREWS 830592, 6) SCRREWS 830506, 2) MAGNETIC BRACKETS 926525, 1) TOP LOUVER FRAME RH 893764
GRILL KIT, T-49 ALL RH MAGNETI W/MOUNTING BRKTS INCLUDES: 1)928664 GRILL, 2) 926524 BRACKETS, 4) 926534 MAGNETIC CATCH, 8) 830566 SCREWS, 2)913451 SCREWS, 2) 927441 SUPPORT BRACKET, 8) 830592 SCREWS, 928718 RETROFIT INSTRUCTIONS
GRILL KIT, T-49 ALL LH MAGNETI W/MOUNTING BRKTS INCLUDES: 1)928665 GRILL, 2) 926524 BRACKETS, 4) 926534 MAGNETIC CATCH, 8) 830566 SCREWS, 2)913451 SCREWS, 2) 927441 SUPPORT BRACKET, 8) 830592 SCREWS, 928718 RETROFIT INSTRUCTIONS
GRILL KIT, T-49 LH/RH MAGNETIC W/MOUNTING BRKTS INCLUDES: 1)928666 GRILL, 2) 926524 BRACKETS, 4) 926534 MAGNETIC CATCH, 8) 830566 SCREWS, 2)913451 SCREWS, 2) 927441 SUPPORT BRACKET, 8) 830592 SCREWS, 928718 RETROFIT INSTRUCTIONS
GRILL ASM T-49G WIRE HIDE INCLUDES: 5) ROUNDED LOUVERS 893742, 1) LEFT ROUNDED LOUVER END965187, 1) RIGHT ROUNDED LOUVER END 965185, 8) SCREWS 830592, 8) SCREWS 830566, 2) MAGNETIC BRACKETS 926534, 1) TOP LOUVER FRAME RH/LH 967100
FASTENER, LATCH FASTEX #7800-02-9909 THIS IS A SQUARE PLASTIC PIECE ON MOUNTING BRACKET. LOCATED ON GRILL MOUNTING BRACKET AND INSERTED INTO SQUARE HOLES. SERVES AS A BASE FOR THE STRIKER TO GO THROUGH TO SECURE GRILL TO MOUNTING BRACKET. REQUIRES 2 PER MOUNTING BRACKET.
