TSSU-60-16-HC

AIR BAFFLE - Part #: 210675

DUCT, LEFT/RIGHT, CLEAR

USED AFTER 7/23/17 PER PCN 9634

DUCT, LT/RT TSSU-60 HC CLR FALSE BOTTOM - REQUIRES 2

AIR VENT - Part #: 209986

FALSE BOTTOM, CLEAR ALUMINUM

FALSE BTM, BAFFLE TSSU-72 CLR

AIR VENT - Part #: 812617

FALSE BOTTOM BRACKET, CLEAR ALUMINUM

HOLDS FALSE BOTTOM IN PLACE

FALSE BTM, BAFFLE TSSU-48/60/ 72 CLR

BLADE - Part #: 946849

BLADE, FAN MOTOR, EVAPORATOR, 115V

BLADE, FAN AD7.75CCW32UBA EVAPORATOR FAN BLADE, 5-BLADES W/ 32 DEGREE PITCH

BLADE - Part #: 947039

BLADE, FAN MOTOR, CONDENSER, 220V 50/60HZ & CE

PER PCN 6947. REPLACED THE 801005 220V ONLY

BLADE, FAN AD8.75CW32UBA CONDENSER FAN BLADE, 5-BLADES W/ 32 DEGREE PITCH

BOLT - Part #: 975519

BOLT, COMPRESSOR MOUNTING

NSF REQUIRES NO THREADS BE EXPOSED ON COMPRESSOR BOLTS.

BOLT, 5/16 UNTHREADED .08 HOLE USED TO BOLT COMPRESSOR TO BASE

BRACKET - Part #: 206048

BRACKET, DRAIN PAN, CONDENSATE

STANDARD

DRAIN PAN BRKT KIT TUC-60-HC GALVANIZED METAL BRACKET UNDER THE CABINET THAT SUPPORTS THE CONDENSATE DRAIN PAN. INCLUDES 203210 BRACKET AND 6)830592 SCREWS

BRACKET - Part #: 206050

BRACKET, FAN MOTOR MOUNT KIT, CONDENSER

COND MOTOR MOUNT KIT TUC-60-HC INCLUDES 203205 BRACKET AND 5)830592 SCREWS

BRACKET - Part #: 206051

BRACKET, CONDENSER FAN KIT

COND FAN BRKT KIT TUC-60-HC INCLUDES 203206 BRACKET AND 3)830592 SCREWS

BRACKET - Part #: 209982

BRKT, FALSE BTM SIDES CLR

USES 2

BRKT, FALSE BTM SIDES CLR

BRACKET - Part #: 209984

SUPPORT, FALSE BOTTOM, CLEAR ALUMINUM

USED AFTER 7/22/17 PER PCN 9634 USES 1

BRKT, FALSE BTM FRONT CLR USED AFTER 7/23/17 PER PCN 9634

BRACKET - Part #: 809961

BRACKET KIT, CUTTING BOARD, 11 3/4"

USED AFTER APPROXIMATELY 3/4/19 PER PCN-10245. USED WITH CUTTING BOARDS WITHOUT HOLES.

CUTTING BOARD BRKT KIT 11 3/4 INCLUDES: 1) 224102 BRACKET, 1) 224103 BRACKET, 4) 971618 SCREWS. PCN-10245

BRACKET - Part #: 814392

BRACKET KIT, CUTTING BOARD, 19"

USED AFTER APPROXIMATELY 3/4/19. USED WITH CUTTING BOARDS WITHOUT HOLES. PCN- 11967

CUTTING BOARD BRKT KIT 19" TSSU OVERHANG INCLUDES: 832748 FRONT LEFT BRACKET, 832747 FRONT RIGHT BRACKET, 222526 BACK LEFT BRACKET, 222527 BACK RIGHT BRACKET, 224187 RIVNUT TOOL KIT, 814391 INSTRUCTIONS

BRACKET - Part #: 814393

BRACKET KIT, CUTTING BOARD, 11 3/4, W/OVERHANG

USED AFTER APPROXIMATELY 3/3/19 WHEN CUTTING BOARD OVERHANGS THE COUNTERTOP. PCN-10846

CUTTING BOARD BRKT KIT 11 3/4" TSSU OVERHANG INCLUDES: 809230 BRACKET, 809231 BRACKET, 222526 BRACKET, 222527 BRACKET, 224187 RIVNUT TOOL KIT, 814391 INSTRUCTIONS

BRACKET - Part #: 848807

LID HINGE BRACKET KIT, FLAT LID, LEFT, SS

USED AFTER 6/14/21 PER PCN-9801 ON FLAT LIDS

LID HINGE BRACKET KIT, LT SS INCLUDES: 215504 SS LID HINGE BRACKET, 3) 971618 SCREWS

BRACKET - Part #: 848808

LID HINGE BRACKET KIT, FLAT LID, RIGHT, SS

USED AFTER 6/14/21 PER PCN-9801 ON FLAT LIDS

LID HINGE BRACKET KIT, RT SS INCLUDES: 215505 SS LID HINGE BRACKET, 3) 971618 SCREWS

BRACKET - Part #: 874656

CUTTING BOARD BRACKET KIT, 11-5/16"L WITHOUT RIVNUT TOOL KIT

USED AFTER APPROXIMATELY 3/3/19 PER PCN-10245. ALSO USE FOR 19" CUTTING BOARD. SET OF 2 - ONE RIGHT/ONE LEFT.

BRACKET KIT CUT BOARD 11-1/3" SET OF 2 FOR 19" CUTTING BOARD. - INCLUDES: 1)864770 RIGHT, 1)864769 LEFT 4) 947854 SCREWS.

BRACKET - Part #: 874659

BRACKET KIT, CUTTING BOARD, 6"L, OPTION

REQUIRES 874642 RIVNUT TOOL KIT TO FIELD INSTALL.

BRACKET KIT CUT BOARD 6" SET2 SET OF 2. USED WITH CUTTING BOARDS WITH HOLES PRE DRILLED. INCLUDES: 2)863102 BRACKETS 4) 947854 SCREWS, 883126 INSTRUCTIONS

BRACKET - Part #: 881328

BRACKET KIT, 19" CUTTING BOARD/RIVNUT TOOL KIT

USED BEFORE 3/3/19 FOR OVERHANG CUTTING BOARD USE FOR 19" CUTTING BOARD. SET OF 2 - ONE RIGHT/ONE LEFT.

BRACKET KIT CUT BOARD 11-1/3" W/RIVNUT TOOL KIT ALSO USED FOR 19" CUTTING BOARD. INCLUDES: 2 BRACKETS ONE 1)864769 LEFT AND ONE 864770)RIGHT, 4)830501 SCREWS, 1)874642 8/32 RIVNUT TOOL KIT TO INSTALL. **USED WITH 926551 CUTTING BOARD PINS**

BRACKET - Part #: 881540

BRACKET KIT, CUTTING BOARD, 6"L, W/ RIVNUT TOOL, OPTION

BRACKET KIT CUT BOARD, 6" 1)874642 TOOL KIT, 2)863102 INCLUDES: 1)874642 RIVNUT TOOL, 2)863102 BRACKETS, 4)978651 SCREWS, 883126 INSTRUCTIONS

BRACKET - Part #: 920399

BRACKET, SNEEZE GUARD, NON-MEGA, SET/3

SNEEZE GUARD BRACKET KIT, TSSU NON MEGA SET/3 BRKTS INCLUDES: 3) 914968 BRACKETS, 4) 947854 BOLTS ATTACH GUARD TO RAIL,6)831509 SCREWS BRACKET TO BACK, 6) 811228 PLUGS, 6) 830617 WASHERS

BRACKET - Part #: 922478

BRACKET KIT, CUTTING BOARD, 6"L, OPTION

USE WITH ANY 3/4" THICK CUTTING BOARD

BRACKET KIT CUT BOARD 6" FOR 3/4" THICK CUTTING BOARDS. SET OF 2. INCLUDES 4) 823064 SCREWS, 2)892517 BRACKETS

BRACKET - Part #: 990728

BRACKET, EVAPORATOR FAN MOTOR, STAINLESS

EVAP FAN MOTOR BRKT KIT TUC-48 HC INCLUDES 985386 BRACKET AND 4)830592 SCREWS REPLACES THE 985385BRACKET

BRACKET - Part #: 998241

SUPPORT, FALSE BOTTOM, CLEAR ALUMINUM

USED BETWEEN 2/23/16 AND 7/22/17 PER PCN 9634

BRACKET, FALSE BTM FRONT TSSU 48 USED BETWEEN 2/23/16 AND 7/22/17 PER PCN 9634
